Description
Features
[ALIJOS TWO-SPEED REELS]
17-4 grade stainless steel main and pinion gears
Carbonite Dual Force Drag system with Cal’s drag grease
6-NMB corrosion resistant stainless steel bearings
Spool bearings feature TSI-301 oil for unmatched freespool
Rigid 1-pcs frame and left sideplate construction
6061-T6 machined aluminum frame and sideplates
Cold forged, Type-II anodized, machined aluminum spool
Custom designed thrust bearing: Alleviates side load on heavy drag settings
Silent retrieve system for ultimate cranking smoothness
90mm handle arm, increases cranking leverage/power
Oversized T-Bar handle on all models, for cranking power
Lug and plug harness system featured on 12 and 16 sizes
External adjustable cast control system on left sideplate
CRC: Corrosion Resistant Coating process
[ALIJOS SINGLE-SPEED LEVER DRAG REELS]
Optimized for fishing consistent light drag settings
Features TDC drag cams for gradual drag curves
High speed 6.4:1 gear ratios for quick line recovery
17-4 grade stainless steel main and pinion gears
Carbonite Drag system with Cal’s drag grease
6-NMB corrosion resistant stainless steel bearings
Dual anti-reverse system (Mechanical and roller bearing)
QuickSet anti-reverse bearing allows for zero handle back play
Rigid 1-pcs frame and left sideplate construction
6061-T6 machined aluminum frame and sideplates
Cold forged, Type-II anodized, machined aluminum spool
Silent retrieve system for ultimate cranking smoothness
Lug and plug harness system featured on 12 and 16 sizes
CRC: Corrosion Resistant Coating process
Technology
MACHINED RIGID FRAME CONSTRUCTION
Okuma’s Machined Rigid Frame construction incorporates a one-piece fully-machined aluminum frame. These rigid bar-stock aluminum frames are the ultimate in precision alignment and tolerances withstanding more pressure and torque than any other material used in our industry for frame materials.
17-4 GRADE STAINLESS STEEL MAIN AND PINION GEARS
DUAL FORCE DRAG SYSTEM
This drag system is specifically engineered to be mounted in the right side of the spool, designed around a Pull Bar Drag System which keeps all mechanical workings in precise alignment and places no pressure on the frame.
SPECIFICATION
Alijos 2-speed Reels
Model: AJ-5II
Gear ratio: 6.4:1 & 3.8:1
Bearings: 6BB+1TB
Weight (g): 560
Line retrieve (cm): 107 & 63
Max Drag Force (kg): 11 & 7
Monofilament line capacity, (diameter in mm.): 0.32/570, 0.37/400, 0.42/320
Model: AJ-5NII
Gear ratio: 6.4:1 & 3.8:1
Bearings: 6BB+1TB
Weight (g): 550
Line retrieve (cm): 107 & 63
Max Drag Force (kg): 11 & 7
Monofilament line capacity, (diameter in mm.): 0.32/385, 0.37/275, 0.42/225
Model: AJ-12II
Gear ratio: 4.7:1 & 2.1:1
Bearings: 6BB+1TB
Weight (g): 810
Line retrieve (cm): 90 & 40
Max Drag Force (kg): 15.5 & 12.3
Monofilament line capacity, (diameter in mm.): 0.42/510, 0.48/380, 0.55/290
Model: AJ-12SII
Gear ratio: 6.4:1 & 2.1:1
Bearings: 6BB+1TB
Weight (g): 820
Line retrieve (cm): 123 & 40
Max Drag Force (kg): 15.5 & 12.3
Monofilament line capacity, (diameter in mm.): 0.42/510, 0.48/380, 0.55/290
Model: AJ-12NSII
Gear ratio: 6.4:1 & 2.1:1
Bearings: 6BB+1TB
Weight (g): 780
Line retrieve (cm): 123 & 40
Max Drag Force (kg): 15.5 & 12.3
Monofilament line capacity, (diameter in mm.): 0.42/300, 0.48/200, 0.55/150
Model: AJ-16II
Gear ratio: 4.3:1 & 1.3:1
Bearings: 6BB+1TB
Weight (g): 1030
Line retrieve (cm): 100 & 30
Max Drag Force (kg): 21.7 & 15.5
Monofilament line capacity, (diameter in mm.): 0.42/800, 0.48/600, 0.55/450
ALIJOS Single-Speed / Special Edition
Model: AJ-12S SE
Gear ratio: 6.4:1
Bearings: 6BB+1RB
Weight (g): 720
Line retrieve (cm): 123
Max Drag Force (kg): 4.6 & 2.6
Monofilament line capacity, (diameter in mm.): 0.42/510, 0.48/380, 0.55/290
Model: AJ-16S SE
Gear ratio: 6.4:1
Bearings: 6BB+1RB
Weight (g): 890
Line retrieve (cm): 149
Max Drag Force (kg): 4.6 & 2.6
Monofilament line capacity, (diameter in mm.): 0.42/800, 0.48/600, 0.55/450
