Description
Features
DFD: Precision Dual Force Drag system
Precision click drag adjustment for more precise settings
Multi-disc, Carbonite and felt drag washers for DFD
6HPB + 1RB corrosion resistant stainless steel bearings
Quick-Set anti-reverse roller bearing plus ratchet system
Dual anti-reverse system for maximum security
Azores-40 size only features the Quick-Set anti-reverse function
Precision machine cut brass pinion gear
CRC: Corrosion-resistant coating process
HDGII: Corrosion-resistant, High density gearing
ALC: Rigid diecast aluminum body, sideplate and rotor
MSS: carbon Mechanical Stabilizing System
Machined aluminum, 2-tone anodized spool with LCS lip
Machined aluminum handle arm for added strength
Hydro Block water tight drag seal
Heavy duty, solid aluminum bail wire
Technology
HIGH PERFORMANCE BEARING
The bearings are more than 10 times more resistant to saltwater than standard stainless steel bearings and even outlast the angler himself.
DUAL FORCE DRAG
Maximize high-end drag pressure, efficiency and overall smoothness.
MECHANICAL STABILIZING SYSTEM
Patented design stabilizes the spool shaft at 3 key stress points to eliminate flex under pressure – reel is more durable, strong and smoother than the competition.
CORROSION RESISTANT COATING
Offer exceptional anti-corrosive properties compared to standard gears, with a coating of corrosion X HD to all internal and external parts.
ALUMILITE FRAME CONSTRUCTION
Provide more precise tolerances for precision gear alignment, maximum cast ability and ultimate durability.
HIGH DENSITY GEARING
HDGII:Corrosion-resistant, High density gearing
SPECIFICATION
High-speed spinning reels
Model: ZXP-4000H
Gear ratio: 5.8:1
Bearings: 6+1
Weight(g): 335
Line retrieve(cm): 91
Max Drag Force(kg): 13
Mono line capacity(mm): 0.25/290, 0.30/200, 0.35/150
Model: ZXP-6000H
Gear ratio: 5.8:1
Bearings: 6+1
Weight(g): 526
Line retrieve(cm): 105
Max Drag Force(kg): 13
Mono line capacity(mm): 0.30/300, 0.35/220, 0.40/170
Model: ZXP-8000H
Gear ratio: 5.4:1
Bearings: 6+1
Weight(g): 720
Line retrieve(cm): 110
Max Drag Force(kg): 20
Mono line capacity(mm): 0.40/250, 0.45/200, 0.50/160
Model: ZXP-14000H
Gear ratio: 5.4:1
Bearings: 6+1
Weight(g): 738
Line retrieve(cm): 120
Max Drag Force(kg): 20
Mono line capacity(mm): 0.40/370, 0.45/290, 0.50/240
Model: ZXP-16000H
Gear ratio: 5.4:1
Bearings: 6+1
Weight(g): 740
Line retrieve(cm): 120
Max Drag Force(kg): 20
Mono line capacity(mm): 0.40/420, 0.45/335, 0.50/270
Low-speed spinning reels
Model: ZXP-6000P
Gear ratio: 4.8:1
Bearings: 6+1
Weight(g): 526
Line retrieve(cm): 87
Max Drag Force(kg): 13
Mono line capacity(mm): 0.30/300, 0.35/220, 0.40/170
Model: ZXP-8000P
Gear ratio: 3.8:1
Bearings: 6+1
Weight(g): 720
Line retrieve(cm): 77
Max Drag Force(kg): 20
Mono line capacity(mm): 0.40/250, 0.45/200, 0.50/160
Model: ZXP-14000P
Gear ratio: 3.8:1
Bearings: 6+1
Weight(g): 738
Line retrieve(cm): 84
Max Drag Force(kg): 20
Mono line capacity(mm): 0.40/370, 0.45/290, 0.50/240
Model: ZXP-16000P
Gear ratio: 3.8:1
Bearings: 6+1
Weight(g): 740
Line retrieve(cm): 84
Max Drag Force(kg): 20
Mono line capacity(mm): 0.40/420, 0.45/335, 0.50/270
