Description
Features
Rigid 1-pcs frame and left sideplate construction
6061-T6 Machined aluminum frame and sideplates
17-4 grade stainless steel main and pinion gears
Carbonite drag system with Cal’s drag grease
Cold forged, Type-II anodized, machined aluminum spool
CRC: Corrosion Resistant Coating process
4 BB corrosion resistant stainless steel bearings
Ergo Grip handle knob with anodized aluminum handle arm
Silent retrieve system for cranking smoothness
On/Off bait clicker for all lever drag models
Technology
MACHINED RIGID FRAME CONSTRUCTION
Okuma’s Machined Rigid Frame construction incorporates a one-piece fully-machined aluminum frame. These rigid bar-stock aluminum frames are the ultimate in precision alignment and tolerances withstanding more pressure and torque than any other material used in our industry for frame materials.
17-4 GRADE STAINLESS STEEL MAIN AND PINION GEARS
ERGONOMIC DESIGN
The Ergo Grip handle knob is an extremely comfortable oversized handle-knob design for both speed and power. This softtouch knob has been ergonomically designed to fit in the palm of your hand.
SPECIFICATION
CAVALLA TWO-SPEED REELS
Model: CAV-5NII
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 460
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/385, 0.37/275, 0.42/225
Model: CAV-5II
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 485
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/570, 0.37/400, 0.42/320
Model: CAV-12NII
Gear Ratio: 4.7:1 & 2.1:1
Bearings: 4BB
Weight (g): 675
Line retrieve (cm): 90 & 40
Max Drag Pressure (kg): 12.2 & 15.4
Mono. line capacity (diameter in mm.): 0.42/300, 0.48/200, 0.55/150
Model: CAV-12II
Gear Ratio: 4.7:1 & 2.1:1
Bearings: 4BB
Weight (g): 705
Line retrieve (cm): 90 & 40
Max Drag Pressure (kg): 12.2 & 15.4
Mono. line capacity (diameter in mm.): 0.42/510, 0.48/380, 0.55/290
Model: CAV-5NIILX*
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 460
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/385, 0.37/275, 0.42/225
Model: CAV-5IILX*
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 485
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/570, 0.37/400, 0.42/320
Model: CAV-12IILX*
Gear Ratio: 4.7:1 & 2.1:1
Bearings: 4BB
Weight (g): 705
Line retrieve (cm): 90 & 40
Max Drag Pressure (kg): 12.2 & 15.4
Mono. line capacity (diameter in mm.): 0.42/510, 0.48/380, 0.55/290
CAVALLA SINGLE -SPEED REELS
Model: CAV-5S
Gear Ratio: 6.4:1
Bearings: 4BB
Weight (g): 465
Line retrieve (cm): 107
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/570, 0.37/400, 0.42/320
Model: CAV-5NS
Gear Ratio: 6.4:1
Bearings: 4BB
Weight (g): 440
Line retrieve (cm): 107
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/385, 0.37/275, 0.42/225
CAVALLA TWO-SPEED REELS WITH T-BAR KNOB
Model: CAV-5NII-TB
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 502
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/385, 0.37/275, 0.42/225
Model: CAV-5II-TB
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 515
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/570, 0.37/400, 0.42/320
Model: CAV-5NIILX-1*
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 502
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/385, 0.37/275, 0.42/225
Model: CAV-5IILX-TB*
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 515
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/570, 0.37/400, 0.42/320
CAVALLA SINGLE-SPEED REELS WITH T-BAR KNOB
Model: CAV-5NS-TB
Gear Ratio: 6.4:1
Bearings: 4BB
Weight (g): 470
Line retrieve (cm): 107
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/385, 0.37/275, 0.42/225
CAVALLA BLUE TWO -SPEED REELS
Model: CAVB-5NII
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 460
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/385, 0.37/275, 0.42/225
Model: CAVB-5II
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 485
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/570, 0.37/400, 0.42/320
Model: CAVB-12NII
Gear Ratio: 4.7:1 & 2.1:1
Bearings: 4BB
Weight (g): 675
Line retrieve (cm): 90 & 40
Max Drag Pressure (kg): 12.2 & 15.4
Mono. line capacity (diameter in mm.): 0.42/300, 0.48/200, 0.55/150
Model: CAVB-12II
Gear Ratio: 4.7:1 & 2.1:1
Bearings: 4BB
Weight (g): 705
Line retrieve (cm): 90 & 40
Max Drag Pressure (kg): 12.2 & 15.4
Mono. line capacity (diameter in mm.): 0.42/510, 0.48/380, 0.55/290
Model: CAVB-5NIILX*
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 460
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/385, 0.37/275, 0.42/225
Model: CAVB-5IILX*
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 485
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/570, 0.37/400, 0.42/320
Model: CAVB-12IILX*
Gear Ratio: 4.7:1 & 2.1:1
Bearings: 4BB
Weight (g): 705
Line retrieve (cm): 90 & 40
Max Drag Pressure (kg): 12.2 & 15.4
Mono. line capacity (diameter in mm.): 0.42/510, 0.48/380, 0.55/290
CAVALLA BLUE TWO-SPEED REELS WITH T-BAR KNOB
Model: CAVB-5NII-TB
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 502
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/385, 0.37/275, 0.42/225
Model: CAVB-5NIILX-TB*
Gear Ratio: 6.4:1 & 3.8:1
Bearings: 4BB
Weight (g): 502
Line retrieve (cm): 107 & 63
Max Drag Pressure (kg): 7 & 11
Mono. line capacity (diameter in mm.): 0.32/385, 0.37/275, 0.42/225
