Description
Features
On/Off auto trip bait feeding system
DFD: Precision Dual Force Drag system
Carbonite drag washers on Dual Force Drag
Heavy duty, brass DFD and spool shaft stabilizer
4HPB+1RB corrosion resistant stainless steel bearings
Quick-Set ant-reverse bearing allows for zero back play in handle
CRC: Corrosion-Resistant Coasting process
Machined aluminum, screw in handle system
Slow oscillation system for improved line lay
Technology
QUICK-SET ANTI-REVERSE
Engage the reel in one direction for rock-solid hook sets.
CYCLONIC FLOW ROTOR
Create “cyclonic” airflow, which significantly increases air around the rotor and allows for a much faster drying time if the reel becomes wet, minimizing corrosion possibilities throughout the reel.
DUAL FORCE DRAG
Maximize high-end drag pressure, efficiency and overall smoothness.
HIGH PERFORMANCE BEARING
The bearings are more than 10 times more resistant to saltwater than standard stainless steel bearings and even outlast the angler himself.
SLOW OSCILLATION SYSTEM
Makes the line wind more straight and tight, reduce the friction when casting.
EVEN FLOW ROLLER SYSTEM
Reduce line twists by freely rolling over the line roller without friction.
ROTOR EQUALIZING SYSTEM
Precision balance and eliminates all spool wobble for perfect alignments and smooth cranking.
HYDRO BLOCK
Block water and foreign materials from entering system, ensure the drag washers always perform at optimal levels.
MULTI-DISC CARBONITE DRAG WASHERS
For a much wider and smoother drag range, maximum efficiency.
SPECIFICATION
Model: CDX-55
Gear ratio: 4.4:1
Bearings: 4HPB+1RB
Weight (g): 550
Line retrieve(cm): 82.6
Max drag force(kg): 12.7
Mono line capacity (mm): 0.30/320, 0.35/230, 0.40/180
Braided line rating(Tuf line): 245/50
Model: CDX-60
Gear ratio: 4.4:1
Bearings: 4HPB+1RB
Weight (g): 563
Line retrieve(cm): 86.7
Max drag force(kg): 12.2
Mono line capacity (mm): 0.30/375, 0.35/275, 0.40/210
Braided line rating(Tuf line): 290/50
Model: CDX-65
Gear ratio: 4.9:1
Bearings: 4HPB+1RB
Weight (g): 822
Line retrieve(cm): 106.0
Max drag force(kg): 15.3
Mono line capacity (mm): 0.40/300, 0.45/235, 0.50/190
Braided line rating(Tuf line): 315/65
Model: CDX-80
Gear ratio: 4.9:1
Bearings: 4HPB+1RB
Weight (g): 855
Line retrieve(cm): 115.3
Max drag force(kg): 17
Mono line capacity (mm): 0.40/380, 0.45/300, 0.50/240
Braided line rating(Tuf line): 235/80
