Description
Features
Compact body
Long Stroke spool 30mm
Corrosion-resistant graphite body
3 ball bearing + 1 roller bearing
Quick Set infinite anti-reverse system
Machine cut aluminum spool
2 round metal line clips
Rigid metal handle with wooden knob
Worm shaft oscillation system
Machined cut brass pinion gear
Heavy duty, solid aluminum bail wire
RESII: Computer-balanced rotor system
Even Flow line roller
Rotor brake system
Fast progressive drag
Technology
COMPACT BODY DESIGN WITH LONG STROKE SPOOL TRIP 30MM
The design of long stroke spool makes the line wind more straight and tight, reduce the friction when casting.
HIGH RIGID CYCLONIC FLOW ROTOR
Cyclonic Flow Rotor (CFR) was designed to create “cyclonic” airflow, which significantly increases air around the rotor, beneath and around the spool, with every turn of the handle. This thoroughly tested design allows for a much faster drying time if the reel becomes wet, minimizing corrosion and extending longevity of the reel.
OVERSIZED GEAR
Okuma redesigns the transmission system, enlarges gearing system and drag system, allows more strength and cranking power, offers a highspeed gear ratio.
ROTOR BRAKE SYSTEM
Prevent rotor to turn around and reverse when casting.
FAST PROGRESSIVE DRAG
This fast progressive drag allows a setting from low drag power to almost full drag power in less than 360° rotation.
PINION GEAR WITH 2 BALL BEARINGS SUPPORTING
Makes the reel smoother, more rigid and durable.
SPECIFICATION
Model: INC-6000
Gear ratio: 5.3:1
Bearings: 3+1
Weight(g): 460
Line retrieve(cm): 104
Max Drag Force(kg): 12
Mono. line capacity(mm): 0.30/370, 0.33/300, 0.35/270
Model: INC-8000
Gear ratio: 5.3:1
Bearings: 3+1
Weight(g): 533
Line retrieve(cm): 123
Max Drag Force(kg): 16
Mono. line capacity(mm): 0.33/440, 0.35/385, 0.38/320
