Description
Features
Open spool bearings with TSI-301 oil. Increases freespool 2-1/2 times.
All non-spool bearings feature full grease pack for maximum longevity.
Features Special Edition Gun Smoke and Black anodizing.
SE reels will feature a yellowfin tuna etched into the side plate.
Frames have been machined out for increased clearance between spool and cross bars.
MK-8/10/15 will feature MK-20 size handle knobs.
MK-20/30 features the MK-50 handle arm and knobs
New lower speed 1.3:1 gear ratio featured in 20/30 sizes.
6061-T6 Machined aluminum frame with forged side plates
17-4 stainless steel gearing
Helical cut gears for increased torque, smoothness and improved gear meshing
Makaira reels all feature two-speed gearing systems
Cold forged, Type-II anodized, machined aluminum spool
CRC: Corrosion-Resistant Coating process
Patented spool pin system for use with braided or mono lines
Carbonite Dual Force Drag system featuring Cal’s universal drag grease
Custom designed thrust bearing: Alleviates side load on heavy drag settings
4-pcs ABEC-5 precision Sapporo stainless steel ball bearings
Double dog, proprietary silent anti-reverse system
Ratcheting drag lever and drag cam for precise drag setting
Patented T-Bar handle with Easy Roll graphite insert on all models
Heavy duty stainless steel ratcheting clicker system
Heavy duty, 17-4 grade stainless steel drive and spool shafts
Type-II gunmetal anodized frame, side plates, spool, drag lever and handle
Open top frame design on MK-5II, 10II, 15II, 20II, 30II
Lug and plug system on all open top reel models
Machined thumb rest on rear cross bar for improved ergonomics
Forged aluminum, full hard anodized reel foot and reel clamp
Precision placement of drain holes maximizes water removal from reel
Special screw ports around side plate screws reduces water/corrosion buildup
Makaira lever drag reels are backed by a 5-year warranty
SPECIFICATION
Two-Speed Lever Drag Reels
Model: MK-15TIISEA-MAHI
Gear ratio: 4.7:1 & 2.1:1
Bearings: 4BB + 1TB
Weight (g): 822
Line retrieve(cm): 98.8 & 43.4
Mono line capacity (mm): 0.45/525, 0.48/385, 0.55/295
Max Drag @ Strike with Freespool: 14.5 kg
Max Drag @ Full with Freespool: 18.2 kg
Frame Style: Topless
Model: MK-16IISEA-MAHI
Gear ratio: 4.3:1 & 1.3:1
Bearings: 4BB + 1TB
Weight (g): 1134
Line retrieve(cm): 99.6 & 30.0
Mono line capacity (mm): 0.42/800, 0.48/600, 0.55/450
Max Drag @ Strike with Freespool: 15.4 kg
Max Drag @ Full with Freespool: 21.7 kg
Frame Style: Topless
Model: MK-20IISEA-MAHI
Gear ratio: 3.8:1 & 1.3:1
Bearings: 4BB + 1TB
Weight (g): 1298
Line retrieve(cm): 100.1 & 33.5
Mono line capacity (mm): 0.48/800, 0.55/600, 0.60/480
Max Drag @ Strike with Freespool: 16.8 kg
Max Drag @ Full with Freespool: 25.0 kg
Frame Style: Topless
Model: MK-30IISEA-MAHI
Gear ratio: 3.8:1 & 1.3:1
Bearings: 4BB + 1TB
Weight (g): 1417
Line retrieve(cm): 100.1 & 33.5
Mono line capacity (mm): 0.55/770, 0.60/640, 0.70/500
Max Drag @ Strike with Freespool: 16.8 kg
Max Drag @ Full with Freespool: 25.0 kg
Frame Style: Topless
Model: MK-50IISEA-MAHI
Gear ratio: 3.2:1 & 1.0:1
Bearings: 4BB + 1TB
Weight (g): 1707
Line retrieve(cm): 96.0 & 30.2
Mono line capacity (mm): 0.55/910, 0.70/590, 0.90/360
Max Drag @ Strike with Freespool: 27.2 kg
Max Drag @ Full with Freespool: 39.0 kg
Frame Style: Topless
Model: MK-50WIISEA-MAHI
Gear ratio: 3.2:1 & 1.0:1
Bearings: 4BB + 1TB
Weight (g): 1843
Line retrieve(cm): 96.0 & 30.2
Mono line capacity (mm): 0.70/820, 0.75/710, 0.90/510
Max Drag @ Strike with Freespool: 27.2 kg
Max Drag @ Full with Freespool: 39.0 kg
Frame Style: Crossbar
Model: MK-80WIISEA-MAHI
Gear ratio: 3.1:1 & 1.2:1
Bearings: 6BB + 1TB
Weight (g): 3289
Line retrieve(cm): 116.1 & 52.1
Mono line capacity (mm): 0.90/910, 1.00/770, 1.12/600
Max Drag @ Strike with Freespool: 32.1 kg
Max Drag @ Full with Freespool: 45.4 kg
Frame Style: Crossbar
Model: MK-130IISEA-MAHI
Gear ratio: 2.2:1 & 1.2:1
Bearings: 6BB + 1TB
Weight (g): 4750
Line retrieve(cm): 100.8 & 55.1
Mono line capacity (mm): 0.90/1450, 1.00/1170, 1.12/920
Max Drag @ Strike with Freespool: 34.1 kg
Max Drag @ Full with Freespool: 45.4 kg
Frame Style: Crossbar
