Description
Features
Open spool bearings with TSI-301 oil. Increases freespool 2-1/2 times.
MK-80WIISEa-MTBLK & MK-130IISEa-MTBLK feature grease-packed spool bearings
All non-spool bearings feature full grease pack for maximum longevity.
Type-II Black anodized frame, sideplates, spool, drag lever & handle
Frames have been machined out for increased clearance between spool & cross bars.
MK-15T feature MK-20 size handle knobs.
MK-20/30 feature the MK-50 handle arm & knobs
Lower speed 1.3:1 gear ratio featured in 20/30 sizes.
Lower speed 1.0:1 gear ratio featured in 50 size.
Technology
DUAL FORCE DRAG
Maximize high-end drag pressure, efficiency and overall smoothness.
CORROSION RESISTANT COATING
Offer exceptional anti-corrosive properties compared to standard gears, with a coating of corrosion X HD to all internal and external parts.
MULTI-DISC CARBONITE DRAG WASHERS
For a much wider and smoother drag range, maximum efficiency.
STAINLESS STEEL GEARING
For ultimate power and strength
MACHINED RIGID FRAME CONSTRUCTION
Okuma’s Machined Rigid Frame construction incorporates a one-piece fully-machined aluminum frame. These rigid bar-stock aluminum frames are the ultimate in precision alignment and tolerances withstanding more pressure and torque than any other material used in our industry for frame materials.
SPECIFICATION
Model: MK-15TIISEa-MTBLK
Gear ratio: 4.7:1 & 2.1:1
Bearings: 4BB + 1TB
Weight (g): 822
Line retrieve (cm): 98.8 & 43.4
Max Drag @ Strike with Freespool (kg): 14.5
Max Drag @ full with Freespool (kg): 18.2
frame style: Topless
Mono Line Capacity, (diameter in mm.): 0.45/525, 0.48/385, 0.55/295
Model: MK-16IISEa-MTBLK
Gear ratio: 4.3:1 & 1.3:1
Bearings: 4BB + 1TB
Weight (g): 1134
Line retrieve (cm): 99.6 & 30.0
Max Drag @ Strike with Freespool (kg): 15.4
Max Drag @ full with Freespool (kg): 21.7
frame style: Topless
Mono Line Capacity, (diameter in mm.): 0.42/800, 0.48/600, 0.55/450
Model: MK-20IISEa-MTBLK
Gear ratio: 3.8:1 & 1.3:1
Bearings: 4BB + 1TB
Weight (g): 1298
Line retrieve (cm): 100.1 & 33.5
Max Drag @ Strike with Freespool (kg): 16.8
Max Drag @ full with Freespool (kg): 25
frame style: Topless
Mono Line Capacity, (diameter in mm.): 0.48/800, 0.55/600, 0.60/480
Model: MK-30IISEa-MTBLK
Gear ratio: 3.8:1 & 1.3:1
Bearings: 4BB + 1TB
Weight (g): 1417
Line retrieve (cm): 100.1 & 33.5
Max Drag @ Strike with Freespool (kg): 16.8
Max Drag @ full with Freespool (kg): 25
frame style: Topless
Mono Line Capacity, (diameter in mm.): 0.55/770, 0.60/640, 0.70/500
Model: MK-50IISEa-MTBLK
Gear ratio: 3.2:1 & 1.0:1
Bearings: 4BB + 1TB
Weight (g): 1707
Line retrieve (cm): 96.0 & 30.2
Max Drag @ Strike with Freespool (kg): 27.2
Max Drag @ full with Freespool (kg): 39
frame style: Topless
Mono Line Capacity, (diameter in mm.): 0.55/910, 0.70/590, 0.90/360
Model: MK-50WIISEa-MTBLK
Gear ratio: 3.2:1 & 1.0:1
Bearings: 4BB + 1TB
Weight (g): 1843
Line retrieve (cm): 96.0 & 30.2
Max Drag @ Strike with Freespool (kg): 27.2
Max Drag @ full with Freespool (kg): 39
frame style: Crossbar
Mono Line Capacity, (diameter in mm.): 0.70/820, 0.75/710, 0.90/510
Model: MK-80WIISEa-MTBLK
Gear ratio: 3.1:1 & 1.2:1
Bearings: 6BB + 1TB
Weight (g): 3289
Line retrieve (cm): 116.1 & 52.1
Max Drag @ Strike with Freespool (kg): 32.1
Max Drag @ full with Freespool (kg): 45.4
frame style: Crossbar
Mono Line Capacity, (diameter in mm.): 0.90/910, 1.00/770, 1.12/600
Model: MK-130IISEa-MTBLK
Gear ratio: 2.2:1 & 1.2:1
Bearings: 6BB + 1TB
Weight (g): 4750
Line retrieve (cm): 100.8 & 55.1
Max Drag @ Strike with Freespool (kg): 34.1
Max Drag @ full with Freespool (kg): 45.4
frame style: Crossbar
Mono Line Capacity, (diameter in mm.): 0.90/1450, 1.00/1170, 1.12/920
