Description
Features
Lightweight and Lower profile, corrosion-resistant frame and sideplates
Multi-disc, Carbonite drag system
Aluminum handle arm with Ergo Grip handle knobs
2BB + 1RB Stainless steel ball bearings
Self-lubricating gearing system, all models
Machined aluminum, two tone anodized spool
Dual anti-reverse system. (Mechanical and roller bearing)
More durable Mechanical line counter function measures in feet
CVT: Clear View Technology anti-fogging line counter
Aluminum ratcheting drag star for precision drag settings
Wide Mouth Levelwind: Clearance for copper lines
Automatic trip, spool engaging mechanism
Upgrade 6-pin Onewayto 10 pin
Technology
COMPACT, LOW-PROFILE AND CORROSION-RESISTANT BODY
A more compact and low-profile design allows the body to be closer to the foot, improving weight distribution and enhancing stability while fishing.
MULTI-DISC CARBONITE DRAG SYSTEM
The newly designed, all-out 4-piece carbonite brake system offers superior strength, durability, and smoothness for ultimate stopping power.
UPGRADED 10-PIN ONEWAY BEARING
The 10-pin one-way bearing ensures better precision and durability, enhancing overall performance and reliability.
SPECIFICATION
COLD WATER LINE COUNTERS
Model: CW-15DA
Gear ratio: 5.1:1
Bearings: 3+1
Weight (g): 419
Line retrieve(cm): 63
Max drag force(kg): 8.5
Mono line capacity (mm): 0.35/220,0.40/170,0.45/130
Model: CW-20DA
Gear ratio: 5.1:1
Bearings: 3+1
Weight (g): 431
Line retrieve(cm): 63
Max drag force(kg): 8.5
Mono line capacity (mm): 0.35/270,0.40/210,0.45/150
Model: CW-30DA
Gear ratio: 4.3:1
Bearings: 3+1
Weight (g): 567
Line retrieve(cm): 69
Max drag force(kg): 9.5
Mono line capacity (mm): 0.40/420,0.45/320,0.50/260
Model: CW-45DA
Gear ratio: 4.2:1
Bearings: 3+1
Weight (g): 618
Line retrieve(cm): 75
Max drag force(kg): 9.5
Mono line capacity (mm): 0.45/450,0.5/360,0.55/300
Model: CW-15DLA
Gear ratio: 5.1:1
Bearings: 3+1
Weight (g): 419
Line retrieve(cm): 63
Max drag force(kg): 8.5
Mono line capacity (mm): 0.35/220,0.40/170,0.45/130
Model: CW-20DLA
Gear ratio: 5.1:1
Bearings: 3+1
Weight (g): 431
Line retrieve(cm): 63
Max drag force(kg): 8.5
Mono line capacity (mm): 0.35/270,0.40/210,0.45/150
Model: CW-30DLA
Gear ratio: 4.3:1
Bearings: 3+1
Weight (g): 567
Line retrieve(cm): 69
Max drag force(kg): 9.5
Mono line capacity (mm): 0.40/420,0.45/320,0.50/260
COLD WATER HIGH-SPEED LINE COUNTERS
Model: CW-30DHA
Gear ratio: 6.2:1
Bearings: 3+1
Weight (g): 570
Line retrieve(cm): 99
Max drag force(kg): 9.5
Mono line capacity (mm): 0.40/420,0.45/320,0.50/260
Model: CW-45DHA
Gear ratio: 6.4:1
Bearings: 3+1
Weight (g): 624
Line retrieve(cm): 115
Max drag force(kg): 9.5
Mono line capacity (mm): 0.45/450,0.5/360,0.55/300
Model: CWL-55HA
Gear ratio: 4.7:1
Bearings: 3+1
Weight (g): 890
Line retrieve(cm): 105
Max drag force(kg): 10
Mono line capacity (mm): 0.50/570,0.55/470,0.60/440
