Description
Features
MRF : Full machined aluminum frame and side plate
XL GEAR : Oversize Stainless steel gearing
Cold forged, Type-II anodized, machined aluminum spool
FLITE SPOOL™ for super tuned and long casting
MCS : External adjustable magnetic cast control system
CARBON DRAG : Carbonite high output drag with Cal’s drag grease
Heavy duty, stainless steel gear shaft and spool shafts
Precision placement of drain holes maximizes water removal from reel
Aluminum handle arm for strength and light weight carbon knob
CRC : Corrosion Resistant Coating process
Spool pin system for use with braided lines
Double anti-reverse system : OWC and ratchet mechanisms
Braid line only
Technology
FLITE SPOOL™
The ultra-light spool can accommodate a wider range of lure weights, increasing versatility. Its lightness also effectively enhances casting distance.
MACHINED RIGID FRAME CONSTRUCTION
Okuma’s Machined Rigid Frame construction incorporates a one-piece fully-machined aluminum frame. These rigid bar-stock aluminum frames are the ultimate in precision alignment and tolerances withstanding more pressure and torque than any other material used in our industry for frame materials.
XL GEAR : OVERSIZE STAINLESS STEEL GEARING
To achieve fast and effortless reeling, the XL gear is paired with a 7.0 high gear ratio. This effectively reduces the number of handle turns needed, making retrieval easier while significantly enhancing gear durability.
MCS
External adjustable magnetic cast control system.
LUMINUM HANDLE ARM FOR STRENGTH AND LIGHT WEIGHT CARBON KNOB.
SPECIFICATION
Model: TM-10WXA
Gear Ratio: 7.0:1
Bearing: 6BB+1RB
Weight (g): 542
Spool OD/W (mm, ): 58/47
Line Retrieve (cm): 120
Max Drag Pressure (kg): Strike:12, Full:15
Handle Length (mm): 93/105
Braid Line Capacity: LB/YD: 65/410 80/320 100/270, No./M: 6/380 8/300 10/250, Ø mm/M: 0.42/380 0.48/300 0.52/250
Model: TM-10WXLA
Gear Ratio: 7.0:1
Bearing: 6BB+1RB
Weight (g): 542
Spool OD/W (mm, ): 58/47
Line Retrieve (cm): 120
Max Drag Pressure (kg): Strike:12, Full:15
Handle Length (mm): 93/105
Braid Line Capacity: LB/YD: 65/410 80/320 100/270, No./M: 6/380 8/300 10/250, Ø mm/M: 0.42/380 0.48/300 0.52/250
